Product Details:
|
| Product Name: | Single Needle Industrial Sewing Machine | Max. Sewing Speed: | 2200(r.p.m) |
|---|---|---|---|
| Max.Stitch Length: | 0-6.5 Mm | Diameter Of Cylinder Bed: | 65mm |
| Needle Size: | DP*17 (21#) | Hook: | Small Vertical Hook |
| Lubrication: | Manual Lubrication | Working Space: | 250×110mm |
| High Light: | 250*110mm Industrial Sewing Machine,6.5mm stitch industrial Sewing Machine,250*110mm Manual Lubrication Sewing Machine |
||
High Speed Single Needle Socket Cylinder Bed Industrial Sewing Machine
Product introduce
This is an ordinary splice sewing machine with manual oil supply, sliding rod thread take-up, vertical rotary hook thread hooking to form a double-thread lock stitch, and the upper and lower shafts are driven by synchronous toothed belts. The presser foot, the feed dog, and the needle feed synchronously, and the lever type stitch length adjustment mechanism. The high-pressure foot stroke, the high-pressure foot improves the gap and the large stitch length, and is matched with the cylindrical sewing table, which is suitable for the stitching of school bags, travel backpacks, rucksacks, handbags, etc.
Product advantages
The housing part where the shuttle bed and needle plate structure is installed is made of high-precision steel instead of cast iron material, which completely solves the problem of slippage and fracture in this part, and greatly improves the service life. Optional clutch motor, electronic energy-saving motor (including fixed needle, adjustable speed), using the new black gold steel tooth frame, precise selection of spare parts, durable.
Parameter of machine
| Model | JL-8B-J |
| Number of Needle | Single Needle |
| Max. Sewing Speed | 2200(r.p.m) |
| Max.Stitch Length | 0-6.5mm |
| Diameter of Cylinder Bed | 65mm |
| Presser foot lift | 8 mm (by hand ) 14 mm (by knee) |
| Needle size | DP*17 (21#) |
| Hook | Small Vertical Hook |
| Lubrication | Manual Lubrication |
| Working Space | 250*110mm |
| motor | Clutch Electric Motor, Electronic Energy-saving Machine |
| Mechanical Configuration | Cylinder-bed |
| Feed Mechanism | Compound Feed |
| Dimensions | 66.6*26.6*51cm |
| Color | White |
| N.W | 32KG |
Applications
Suitable for operations in luggage, handbags, and leather factories.
Product details
1. The nozzle can be replaced by the design of the nozzle, which completely solves the problem of broken teeth in this part, and greatly extends the service life of the machine.
2, Thread clamp, adjust the tension of the upper thread.
FAQ
|
Q1. Is your company a factory or trading company? A. We are sewing machine factory, we focus on excellence sewing machine.
|
Q2. How about your machine quality? A. I cannot answer to you from our side. But our customer said to us our machine quality is good and use it about two years no change voice. After you use it, you will more understand our quality. |
|
Q3.How about your price? |
|
Q4. Can I buy one or two pieces? |
|
Q5. How can I get a quotation? A. First please give us your email address and which machine are your interesting.
|
